![](uploadfiles/7txt/2014-04-03-14-01-357.jpg) Abrasion Resistant PVC Sand Suction Hose
Material: Tube wall is made from Special macromolecule wear-resistant material, spirals made of hard PVC material. The tube wall is covered with solid spiral PVC stripe. Quality: Good abrasion resistance, fluency, good chemical resistance, acid and alkali resistance. Temperature range: -20¡æ to +80¡æ
Applications:
1: Abrasive powers, shards and granules with high flow rate;
2: Transportation of all kinds of sandblasting abrasives, such as steel grits, ceramic balls, steel shots, concrete granules;
3: Painting and surface treatment of docks, steel and iron plants, shipyards.
Parameter Table£º
I.D. |
O.D.(ref.) |
Working Pressure |
Bursting Pressure |
Maximum |
inch |
(mm) |
(mm) |
(MPa) |
(Mpa) |
Length(m) |
11/2 |
38 |
49 |
0.15 |
0.8 |
20 |
2 |
50 |
60 |
0.12 |
0.5 |
20 |
2 1/2 |
63 |
75 |
0.12 |
0.5 |
20 |
3 |
75 |
85 |
0.12 |
0.5 |
20 |
4 |
100 |
120 |
0.12 |
0.5 |
20 |
5 |
125 |
140 |
0.12 |
0.5 |
20 |
6 |
150 |
170 |
0.12 |
0.5 |
20 | |
