Position: Home >> Products >> Diesel Water Pumps
Product Class : Diesel Water Pumps
Product Name : Water Cooled Deutz Diesel Engine Pump
 Enlarge Image                   Back




Water Cooled Deutz Diesel Engine Pump

P & H Series pumps are interchangeable parts and dimensions with many OEM self-priming non-clog trash pumps (including entire rotating assemblies),it designed for economical & trouble-free operation in handling solids-laden liquids and slurries, it handle up to 76.2mm spherical solids.



Typical mounting configurations are Engine Driven for Skid or Trailer Mounted packages and
Frame Mounted
Electric Driven.  Pumps also are available in a variety of different metallurgies.

Haihe Standard Self-Priming Series pumps provide solutions to your solids handling or clear liquid service needs.



Additional Features Include:

♦  Replaceable Wear Plate
♦  Heavy Duty Suction Flapper
♦  Removable Inspection Cover allows Clean-out, Impeller, Seal and Flapper without disturbing Piping
♦
Semi-Opened Trash Handling Impeller
♦  Pressure Relief Valve
♦  O-Ring Sealed
♦  External, Shimless Impeller/Wear plate Clearance Adjustment
♦  Back Pull-out Cartridge-type Rotating Assembly for Ease of Maintenance

♦
Cartridge Type Mechanical Seal for Ease of Maintenance



Industries Served

a)         ♦  Construction  ♦  Industrial  ♦  Municipal  ♦  Agricultural  ♦  Mining  ♦  Dewatering

b)         ♦  Industrial Waste  ♦  Sewage  ♦  Oil Field  ♦  Petrochemical  ♦  Paper Mills

c)        ♦  Processing



Mounting Configuration
1) Frame Mounted
2) Base Mounted Electric Driven
3) Engine Driven SAE Mounted
4) Engine Driven Skid or Trailer Packages
5) Horizontal or Vertical V-Belt Driven

Technical Data

MODEL

R.P.M.
R/MIN

FLOW
m3/H

TOTAL
HEAD
m

MOTOR
HP

NET
WEIGHT
kg

GROSS
WEIGHT
kg

MAX
SOLIDS
mm

P-2

1150-2900

46

36

1 – 10 HP

100

120

44.45

P-3

650-2150

107

35

1 – 20 HP

183

205

63.5

P-4

650-1950

163

36

1 – 30 HP

290

310

76.2

P-6

650-1550

330

33

2 – 40 HP

395

420

76.2

P-8

650-1350

600

34

7.5 – 75 HP

720

750

76.2

P-10

650-1450

775

40

10 – 100 HP

760

800

76.2

P-12

650-1250

1275

42

20 – 125 HP

1260

1300

76.2

H-3

850-2150

85

62

1.5 – 25 HP

205

225

20.63

H-4

850-2150

148

58

3 – 40 HP

320

350

28.57

H-6

850-1950

308

57

5 – 75 HP

415

450

31.75


Structure & Cutting Drawing
