IS/IR series single-stage, single-suction end suction centrifugal pump designed by the performance and size according to international standard IS02858, its technique standard is close to the international standard and reach international advanced level.
IS /IR has wide use range, there are about 140 kinds of type, but only has four shaft, the same regular of shaft, bearing, impeller can change with each, only four type of pump suspension.
Applications
1. Agriculture irrigation
2. Fire-fighting system
3. Industrial water supply
3. Drainage
4. Civil engineering
Technical Data
1) Max.flow: 400m3/h
2) Ma.head: 125m
3) Max.temperature: IS≤80℃, IR≤120℃
4) Allowed suction pipeline pressure is 0.3Mpa, the highest using pressure: 1.06Mpa
Standard Material
1: Casing: Cast iron and Ductile iron, stainless steel
2: Shaft: Carbon steel or Stainless steel
3: Impeller: Cast iron, ductile iron, Stainless steel, bronze
4: Shaft seal: Mechanical seal or Gland packing seal
Mounting Configuration
1. Frame Mounted
2. Base Mounted Electric Driven
3. Engine Driven SAE Mounted
4. Engine Driven Skid or Trailer Packages
5. Horizontal or Vertical V-Belt Driven
